9CH066-057 - Seagate 300GB 15000RPM SAS 3Gb/s 16MB Cache 3.5-in HDD
This part is priced per order. Send us your details and we'll get back to you with pricing and lead time — usually within one business day.
SKU 9CH066-057
Seagate 9CH066-057 Cheetah 15K.6 Series 300GB 15000RPM SAS 3Gb/s 16MB Cache (CE) 3.5-Inch Hard Drive
The Seagate Cheetah 15K.6 9CH066-057 is a key performance hard drive for enterprise storage applications. This drive comes in 300GB capacity delivering superior and reliable performance due to a 15,000 RPM spindle speed. Available in 3Gb/s SAS interface which can be adjusted according to the desired configuration of the system. Its 3.5-Inch form factor is compatible with most systems, thus making it suitable for programs that require large data capacity like E-mail, transaction processing, and Storage Area Networks.
- 1.6-million-hours MTBF
- Enhanced error correction
- Second-generation perpendicular recording
- An aesthetic increase at a high speed of 30% or up to 171MB/s
- Seagate PowerTrim technology reduces energy costs by 62% at idle
General Information
| Product Line | Cheetah |
|---|---|
| Product Series | 15K.6 |
| Product Type | Hard Drive |
Technical Information
| Storage Capacity | 300 GB |
|---|---|
| Cache Storage | 16MB |
| Maximum Data Transfer Rate | 3 Gb/s |
| RPM | 15000 |
| Drive Type | Internal |
| Drive Width | 3.5" |
Interfaces/Ports
| Drive Interface | SAS |
|---|---|
| Interface Standard | 3Gb/s SAS |
Miscellaneous
| Compliance Standards | CE |
|---|
Also known as — equivalent part numbers
This part is sold under the following identifiers. Search any of them to reach this page.
- Primary part number
- 9CH066-057
